Description
Applications
– Indoor application
– Interface optical communication system
– Telecommunication networks, data communication networks and FTTx
Features :
– Steel cabinet wall mount for indoor application
– Cabinet made from electro galvanize steel 1.2 mm thickness
– Combine splicing function, storing of fiber optical cable, pigtail and patch cord
– Store and protect excess optical cable and patch cord
– Support FC/SC/ST/LC adapter type as below
* FC/ST type support 120 fibers
* SC type support 192 fibers
* LC type support 384 fibers
– Splicing and distribution 12 fibers per tray or 24 fibers per tray
– Support fiber bending radius 30 mm
– Nice Shape, easy installation and maintenance
– Easily fixed by swell bolt, convenient for operation and inspection
– Provide strength member holder to fix the main fiber cable
– Light gray cabinet
Standard :
– Manufactured by ISO 9001-2015 company
Accessories :
– Cable tie and swell bolt
– Adapter, pigtail, splice tray and fusion sleeve as optional
Dimensions :
– 620W x 300D x 530H mm.
