UTP Shielded Modular Patch Panel 24P with Identification Icons (Unloaded)
Click to enlarge

F/UTP Gigalan Augmented CAT6A Patch Cord

Applications

  • Support IEEE 802.3, 10G BASE-T, 1000 BASE T, 1000 BASE TX
  • IEA/TIA-854
  • ANSI/TIA-862, ATM, Video
  • Building Automation System and all previous LAN Protocols

Advantage

  • Exceeds the limits established in the standards ANSI/TIA-568.2-D for CAT6A
  • Guaranteed channel performance 10 Gigabit Ethernet connections for up to 4 connections up to 100 meters (F/UTP)
  • Shielded RJ-45 connector with double claws that ensures better electrical bonding with the cable veins and provides high performance against external noise and interconnection to the grounding system
  • Supplied with Boot, that guarantees the correct bend radius of the installed product and the tension from the installation process
  • Latch protection
  • 100% assembled and tested at the factory

PoE

  • 802.3af and 802.3at

Length

  • From 0.5 up to 20 meters

Color (Default)

  • LSZH : Gray, Blue, Red
  • CM : Gray, Blue and Red

*Others colors (green, white, black) have minimum order quantity must be equivalent 3000 meters of cable

Connector Type

  • RJ-45 shielded

Cable Type

  • F/UTP

Standard

  • ANSI/TIA-568.2-D
  • ISO/IEC 11801
  • IEC 60332-3
  • IEC 61034-2 (smoke density)
  • IEC 60754-2 (Acidity of smoke)
  • IEC 60603-7
  • FCC part 68 subpart F
  • NMX-I-248-NYCE-2008

Certifications

  • CM
  • ETL Verified 100586654CRT-001c
  • UL Listed E173971
  • LSZH
  • ETL Verified 100586662CRT-001b
  • CM and LSZH
  • ETL 4-Channel Verified 101795378CRT-001

RoHS

  • This product is in accordance with the RoHS European Directive: a directive on the restriction of the use of certain hazardous substances and related to the environmental preservation
Part Numbers Product
35085032 F/UTP GIGALAN AUGMENTED CAT6A PATCH CORD – CM – T568A/B – 1.0M – GRAY (SHIELDED)
35085016  F/UTP GIGALAN AUGMENTED CAT6A PATCH CORD – CM – T568A/B – 3.0M – GRAY (SHIELDED)
35085012  F/UTP GIGALAN AUGMENTED CAT6A PATCH CORD – CM – T568A/B – 5.0M – GRAY (SHIELDED)
35085074  F/UTP GIGALAN AUGMENTED CAT6A PATCH CORD – CM – T568A/B – 1.0M – BLUE (SHIELDED)
35085075  F/UTP GIGALAN AUGMENTED CAT6A PATCH CORD – CM – T568A/B – 3.0M – BLUE (SHIELDED)
35085146  F/UTP GIGALAN AUGMENTED CAT6A PATCH CORD – CM – T568A/B – 5.0M – BLUE (SHIELDED)
Price Request
Compare
Categories: , , ,
Description

Description

Installation Environment : Indoor

Operation Environment : Non aggressive

Compatibility : All FCS products

Tracking : Label with serial number on one end

Weight (kg) : 0.035 kg/m

Nominal Diameter : 6.3 mm

Conductor Type : Electrolytic copper, flexible, bare, formed by 7 filaments of nominal diameter of 0.20 mm.

Cable Flammability Rating : CM, CMR or LSZH

Number of Pairs : 4 pairs, 26AWG

Electrical Contact Material : 8-way phosphor bronze with 100μin (2.54 μm) of nikel and 50μin (1.27 μm) of gold

Main Product Material Plug : Transparent thermoplastic material UL 94V-0

Assembly Standard : T568A/B or Cross-over

Operation Temperature (ºC) : -10ºC to +60ºC

Storage Temperature (ºC) : -40ºC to +70ºC

Mated : ≥ 750 RJ-45

Maximum CC Resistance : 140 Ω/km

Maximum Unbalance Resistance : 4%

Maximum Mutual Capacitance @ 1kHz : 56 pF/m

Maximum Propagation Delay : 545ns/100m

Characteristic Impedance : 100±15%Ω

Dielectric Strength : 2500 VDC/3s (Between conductors), 2500VDC/2s (Between each conductor and shield)

NVP (%) : 68 %

Maximum Delay Skew : 45 ns/100m

Package Type : Transparent plastic bag with identification label

Warranty : 12 months
