Connector N Type Female

หัวต่อ Connector แบบ N Type ตัวเมียสามารถใช้กับสายโคแอกเชียลชนิด RG8 และสายฟีดเดอร์ขนาด 1/2″ ได้

Series N are very popular screw-coupling middle power coaxial connectors. Which have the excellent performances of vibration proof, high reliability, superior electrical and mechanical properties, are widely used for communication applications. Connector N Type Female can use for Cable Type RG8 and feeder cable 1/2″.



Price Request
Compare
Categories: , Tags: ,
Description

Description

KEY PERFORMANCE
Temperature range-65 ～ +165°CInsulation resistance≥5000MΩ
Characteristic Impedance50ΩDielectric Withstanding voltage1500V
Frequency range0 ～ 11GHzContact resistanceCenter conductor≤1mΩ
Outer conductor≤0.2mΩ
VSWR≤1.30Durability500

MATERIAL AND PLATING
BodyBrass, gold/nickel plated
Female center contactsBeryllium copper or phosphor bronze, gold plated
InsulatorsPTFE
GasketsSilicone rubber
Crimp ferrulesCopper alloy, nickel plated
