AL-3121S : Shield CAT6 RJ45 In-Line Coupler

Standard

  • ANSI/TIA-568-C.2 Category 6
  • ISO IEC-11801:2017 Class EA
  • EN55024:2010+A1:2015
  • IEEE 802.3an (10G Base T)
  • EMC Compliant
  • RoHS Compliant

Environment

  • Operation Temperature : 0 – 70°C

Electrical

  • Voltage rating : 125 VAC RMS
  • Current rating : 1.5A
  • Contact resistance : 100 mΩ (Min) @500 VDC
  • Dielectric Strength : 750 VAC RMS 60 Hz, 1Min
P/NDescriptions
AL-3121SShield CAT6 RJ45 In-Line Coupler "ALFA BASE"
