AL-2121 : CAT6 RJ45 Modular Jack, IDC

Applications :

  • 10 Base-T (IEEE 802.3)
  • 100 Base-TX (IEEE 802.3u)
  • 1000 Base-T (IEEE 802.3ab)
  • Data Center, VoIP, ISDN, PoE, CCTV and others

Standards :

  • ANSI/TIA-568-C.2 Category 6
  • ISO IEC-11801 : 2017
  • IEEE 802.3ab
  • IEC 60603-7-4, FCC part 68, subpart F
P/NDescriptions
AL-2121CAT6 RJ45 Modular Jack, IDC "ALFA BASE"
Description

Description

Specifications :

  • Voltage rating : 125 VAC RMS
  • Current rating : 1.5 A
  • Contact resistance : 20 mΩ
  • Insulation resistance : 500 mΩ (min) @500 VDC
  • Dielectric strength : 750 VAC RMS 60 Hz, 1 min
  • Operating temperature : -10°C to 60°C
  • RJ45 Jack life : 750 mating cycles with FC compliant 8P plug
  • Contact force : 100 grams with FCC compliant 8P plug
  • Wire contact compatibility : Accommodates AWG 22 – 24
  • Retentiveness of insertion structure : 50N 60±5s

Materials :

  • Housing material : PC
  • Insert material : PC
  • PCB material : FR-4
  • Contact material : Phosphor bonze
  • IDC contact material : Phosphor bonze
