FTTx Fiber Drop Cable (สายใยแก้วนำแสงดรอปเคเบิล)

เป็นสายใยแก้วนำแสงแบบ Drop Cable สำหรับใช้งานในโครงข่าย FTTx

Applications
– Used as terminal connection in FTTx access network
– Used for building horizontal cabling in premises distribution system, especially suitable for horizontal cabling and terminal quick connection

Features
– Good mechanical and environmental performance
– Excellent side pressure protection design
– Flame retardant (or non-flame retarding) characteristic meets the requirements of relevant standards
– Soft, flexible, easy operation and with big capacity data transmission

Description

Description

STRUCTURE & CAPABILITY
PARAMETER
Fiber Count1 - 41 - 4
Cable Dimension (mm.)2.0 x 3.02.0 x 3.0
Cable Weight (kg)8.08.0
STRUCTURE
DescriptionColor Coating Fiber, Strength Member, Jacket
FiberSM : G652D, G655, G657 or other singlemode optical fiber
MM : A1a, A1b, or other multimode fiber
Strength MemberFRP or steel wire
JacketMaterials : flame retardant polyvinyl chloride (PVC), low smoke halogen free flame retardant polyolefin (LSZH) or other materials
FEATURES
ApplicationUsed as terminal connection in FTTx access network
CharacteristicGood mechanical and environmental performance. Flame retardant (or non-flame retarding) characteristic meets the requirements of relevant standards
Temperature-20°C - +60°C
